Overview

The portable sawmill with the rebellious spirit.

  • Honda engine (9HP GX270 / 13HP GX390)
  • Solid steel tubing frame 2X4 1/8
  • Can saw logs up to 30 inches in diameter and 17 feet long
  • Manual saw head positioning
  • User-friendly One-step-Go feature exclusive on every Vallee Portable Sawmills
Specifications
Model
REBEL
Category Name
Forestry
Year
2023
Sale Type
New
Manufacturer
Vallee
engine
  • 9 HP Honda GX270 (manual start) or 13 HP Honda GX390
  • Gasoline, air cooled, 4 stroke, one cylinder, OHC
  • 3-year warranty by the manufacturer
saw head
  • Maximum diameter of log 30 inches
  • Maximum board width 21 inches
  • 7/8 inch last board cut capability
  • Blade of 157’ ½ x 1 1/4 APEX RF (1 blade included)
  • Simple cam lock blade tensioning for fast and easy adjustment
  • Single, One piece solid front panel, for easy access blade maintenance
  • Manual head positioning with a 1700 lb winch capability
  • High grade double bearing blade-guide, Zinc design and adapted for heavy usage with a 18 inch wheel
  • MXV-890 Drive Belt
  • B56 Flywheel Belt
  • Large 7 gallons (26 liters) removable lubrification tank
  • High-Duty frame construction, completely made of 2’’X2’’ solid welds
  • Large colored graduated ruler, details from ¾ up to 4 Inches,
  • Hydraulic blade tensionner available in option - contact your dealer for more information
  • Auto-blade lube system automatically turns on and off fluid flow during operation
  • Automatic Blade-Brake system , maximize speed and the lifespan of your blades
  • Automatic engine throttle and saw Blade engagement.
base
  • Up to 17 feet maximum board length, onto a 20 feet bed
  • Solid steel Tubing frame 2X4 1/8, completely welded with crosspieces, no joints
  • 2 Dog-Log, simple one hand cam-lock design
base option
  • Four foot extra length of cut capability
  • The lengths of all additional tubing in solid steel 2X4 1/8, crosspieces and accessories required.
mobile option
  • 4 adjustable jacks for maximum stability each corner
  • 1 adjustable central levelling stand for solid support
  • 12 inch wheel/tire low speed rating (maximum 70 km/h)
